The DigiTOP VA-3F63A M6W is a multifunctional voltage monitoring relay designed for both single and three-phase systems with a rated current of 63 A. It features a digital display and thermal protection, ensuring accurate voltage monitoring and safety.
| General | |
| Adjustment | digital |
| Current Trip Limit | 40 A |
| Cut-Off Time (Lower Limit) | 0.02 sec |
| Device | voltage Monitoring Relays |
| Dimensions | 105x90x67 mm |
| Functions | display, operation indicator, thermal protection, fault memory |
| Lower Cut-Off Limit | 120 – 200 V |
| Maximum Current | 80 A |
| Measurement Accuracy (±) | 1 % |
| Mount | dIN rail |
| Number Of Phases | 1 / 3 |
| Off Time | 0.02 sec |
| Power | 8.8 kVA |
| Protection Level | IP20 |
| Rated Current | 63 A |
| Reclosing Delay | 5 – 600 sec |
| Upper Cut-Off Limit | 210 – 270 V |
| Voltage | variable |
| Voltage Measuring Range | 50 – 400 V |
| Width (Unit) | 6 U |
DigiTOP VA-3F63A M6W
- Brand: DigiTOP
- Product Code: DigiTOP VA-3F63A M6W
- Availability: In Stock
-
$84.79
